RD—16HTMicrowave processing equipment for printing and dyeing

　　Main technical parameters:

　　○1Product model：RD—16HT

　　○2Power input: three-phase five wire380±10% , 50Hz±1%

　　○3working frequency： 2450MHz±50MHz

　　○4Rated input apparent power：≤24KVA

　　○5Microwave output power：≤16KW（Adjustable power）

　　○6Overall dimensions (L * w * h)：8600×860×1650 mm

　　○7Inlet and outlet height：50mm

　　○8Conveyor width：540mm

　　○9transmission speed：0.5～5m/min

　　○10Water efficiency: about 16 kg per hour

　　○11Control: can add PCL, man-machine interface control, temperature control, monitoring device

　　○12Microwave leakage: according to the national GB10436-89 standard (GB = 5mw/cm2)

　　Accord with national GB5226 electrical safety standard

　　○13work environment：－5~40℃，relative humidity≤80%

　　There is no corrosive gas, conductive dust and explosive gas

　　One, overview:
　　Microwave technology is applied in the dyeing industry, compared with the traditional production process, has obvious advantages. The development of the textile industry will exert a far-reaching influence. It cooperates with other new technologies, can be achieved without pollution of printing and dyeing - environmental protection is still blank in the printing and dyeing, printing and dyeing enterprises at home and abroad.
　　Two, the structure diagram:
　　Dyeing liquid
　　Microwave drying
　　Post treatment
　　Three, characteristics:
　　1, the microwave dyeing completely solves the problem of water pollution in the traditional cylinder dyeing
　　2, the device has a strong stability, reliability and practicality, the process of each of the strict control and control, to avoid the traditional manual machine cylinder dyeing product quality problems
　　3, the traditional dyeing method for several hours, the heat energy loss, the working environment is bad:
　　In a, microwave irradiation, dye movement gradually increased rapidly, the dye molecules dissolved in water diffusion and dyeing in fiber fabric;
　　B, under the rapid vibration of microwave, is more conducive to dye molecules diffusion, penetration and fixation, so the dyeing time is short, generally 1 to 10 minutes, much less than the traditional dyeing time
　　4, reduce environmental pollution, for the benefit of society
　　5, the dyeing fastness, color and other indicators after dyeing are better than the traditional process
　　Four, the scope of application:
　　This product is suitable for polyester fabric, polyester cotton, acrylic fabric, polyester acrylic cloth and so on all kinds of cloth and cotton yarn. The production of microwave drying of our raw materials, dyes, pigments and drying equipment, quickly, 3 times more than ordinary energy-saving drying equipment.
